Magnitude |
:3 |
| Date & Time (UTC) | 2016-05-22 00:08:15.6 |
| Date & Time (Local) | 1395/3/2 04:38:15.6 |
| Location | Lat:30.195 Lon: 49.846 |
| Region | Khoozestan Province, 14 km -East of Hendijan |
Nearest Cities |
|
| 14 km East of Hendijan, Khoozestan Province | |
| 27 km South West of Darunak, Khoozestan Province | |
| 33 km North West of Ameri, Bushehr Province | |
| 34 km South East of Chamkhalf-e eisa, Khoozestan Province | |
| 39 km South West of Sardasht, Khoozestan Province | |
| Depth | 18 km |
| Agency | |
Faults within 150 km: |
|
| RAG_E_SEFID_F (Length: 84 km) , Distance to epicenter: 16 km | |
| AGHAJARI_F (Length: 88 km) , Distance to epicenter: 48 km | |
| ZFF3 (Length: 125 km) , Distance to epicenter: 51 km | |
| Number of Phases | 9 |
| RMS | 0 |
| Number of Stations | 8 |
| Error in Latitude | >6.9 km |
| Error in Longitude | 7.1 km |
| Error in Depth | 11.6 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude | ||||||||
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
| 106262 | IIEES | AHRM | N | 163.9 | 0.54 | 2016-05-22 00:09:24 | 2016-05-23 09:40:00 | n |
| 106263 | IIEES | AHRM | E | 139.4 | 0.46 | 2016-05-22 00:09:29 | 2016-05-23 09:40:00 | n |
| 106264 | IIEES | KHMZ | E | 14.7 | 0.46 | 2016-05-22 00:10:10 | 2016-05-23 09:40:00 | n |
| 106265 | IIEES | NASN | E | 24.2 | 0.92 | 2016-05-22 00:10:25 | 2016-05-23 09:40:00 | n |
| 106266 | IIEES | ASAO | E | 8.2 | 0.37 | 2016-05-22 00:10:20 | 2016-05-23 09:40:00 | n |
| 106267 | IIEES | ASAO | N | 11.4 | 0.82 | 2016-05-22 00:10:28 | 2016-05-23 09:40:00 | n |
| 106268 | IIEES | YZKH | N | 5.8 | 0.67 | 2016-05-22 00:10:24 | 2016-05-23 09:40:00 | n |
| 106269 | IIEES | YZKH | E | 7.1 | 0.47 | 2016-05-22 00:10:25 | 2016-05-23 09:40:00 | n |
| 106270 | IIEES | SNGE | N | 7.1 | 0.47 | 2016-05-22 00:10:38 | 2016-05-23 09:40:00 | n |
Phase | ||||||||||||
| Agency | Station | Component | Phase Type | Phase Quality | First Motion | Observed Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth | |
| IIEES | AHRM | Z | Pg | E | 2016-05-22 00:08:48 | 0 | y | 204 | 136 | |||
| IIEES | AHRM | N | Sg | E | 2016-05-22 00:09:13 | 0 | y | 204 | 136 | |||
| IIEES | KHMZ | Z | Pn | E | 2016-05-22 00:09:11 | -0.03 | y | 393 | 2 | |||
| IIEES | NASN | Z | Pn | E | 2016-05-22 00:09:13 | 0.01 | y | 403 | 44 | |||
| IIEES | ASAO | Z | P | E | 2016-05-22 00:09:23 | 0.03 | y | 483 | 2 | |||
| IIEES | GHVR | Z | Pn | E | 2016-05-22 00:09:24 | 0 | y | 493 | 15 | |||
| IIEES | YZKH | Z | Pn | E | 2016-05-22 00:09:26 | -0.01 | y | 513 | 60 | |||
| IIEES | SNGE | Z | Pn | E | 2016-05-22 00:09:33 | -2.56 | n | 4 | 592 | 337 | ||
| IIEES | KRBR | Z | Pn | E | 2016-05-22 00:09:45 | -0.01 | y | 667 | 90 | |||
