Magnitude |
:4.1 |
| Date & Time (UTC) | 2013-05-24 08:19:57.3 |
| Date & Time (Local) | 1392/3/3 12:49:57.3 |
| Location | Lat:28.56 Lon: 53.53 |
| Region | Fars Province, 7 km Jahrom |
Nearest Cities |
|
| 3 km of Heydarabad, Fars Province | |
| 7 km North of Jahrom, Fars Province | |
| 13 km West of Qotbabad, Fars Province | |
| 19 km North of Hasanabad, Fars Province | |
| 21 km West of Alaviyeh, Fars Province | |
| Depth | 18 km |
| Agency | |
Faults within 150 km: |
|
| SARVESTAN_F (Length: 94 km) , Distance to epicenter: 26 km | |
| QIR_F (Length: 130 km) , Distance to epicenter: 38 km | |
| BAKHTEGAN_F (Length: 94 km) , Distance to epicenter: 59 km | |
| Number of Phases | 7 |
| RMS | 0.2 |
| Number of Stations | 5 |
| Error in Latitude | >3.5 km |
| Error in Longitude | 3.5 km |
| Error in Depth | 6.9 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude | ||||||||
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
| 89419 | IIEES | GHIR | E | 9726.9 | 0.28 | 2013-05-24 08:20:20 | 2013-05-24 09:52:00 | n |
| 89420 | IIEES | GHIR | N | 14425.8 | 0.32 | 2013-05-24 08:20:23 | 2013-05-24 09:52:00 | n |
Phase | ||||||||||||
| Agency | Station | Component | Phase Type | Phase Quality | First Motion | Observed Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth | |
| IIEES | GHIR | Z | Pg | E | 2013-05-24 08:20:08 | -0.05 | y | 60.8 | 241 | |||
| IIEES | GHIR | N | Sg | E | 2013-05-24 08:20:16 | 0.03 | y | 60.8 | 241 | |||
| IIEES | AHRM | Z | Pn | E | 2013-05-24 08:20:31 | -0.09 | y | 221 | 279 | |||
| IIEES | AHRM | E | Sg | E | 2013-05-24 08:20:59 | 0.05 | y | 221 | 279 | |||
| IIEES | YZKH | Z | Pn | E | 2013-05-24 08:20:59 | 0.33 | y | 437 | 13 | |||
| IIEES | NASN | Z | Pn | E | 2013-05-24 08:21:03 | -0.28 | y | 476 | 352 | |||
| IIEES | GHVR | Z | Pn | E | 2013-05-24 08:21:30 | -0.01 | y | 692 | 342 | |||
