Magnitude |
:3 |
| Date & Time (UTC) | 2023-08-02 17:23:19.1 |
| Date & Time (Local) | 1402/5/11 20:53:19.1 |
| Location | Lat:33.045 Lon: 57.473 |
| Region | Yazd Province, 80 km South-East of Tabas |
Nearest Cities |
|
| 19 km West of Arababad, Yazd Province | |
| 28 km South of Dihuk, Yazd Province | |
| 68 km South East of Kerit, Yazd Province | |
| 73 km South of Arsak, Khorasan(center) Province | |
| 77 km South East of Oshtoqran, Yazd Province | |
| Depth | 12 km |
| Agency | |
Faults within 150 km: |
|
| ESFARDIAR_F (Length: 94 km) , Distance to epicenter: 0 km | |
| NAYBAND_F (Length: 258 km) , Distance to epicenter: 7 km | |
| CHESHMEH_ROSTAM_ (Length: 142 km) , Distance to epicenter: 14 km | |
| Number of Phases | 17 |
| RMS | 0.4 |
| Number of Stations | 17 |
| Error in Latitude | >1.3 km |
| Error in Longitude | 1.3 km |
| Error in Depth | 5.7 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude | ||||||||
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
| 184683 | IIEES SC | KKHK | Z | 0.9 | 1 | 2023-08-02 17:24:05 | 2023-08-03 11:29:00 | n |
| 184684 | IIEES SC | KKHK | Z | 0.9 | 1 | 2023-08-02 17:23:45 | 2023-08-03 11:29:00 | n |
| 184685 | IIEES SC | YZKH | Z | 0.1 | 1 | 2023-08-02 17:24:01 | 2023-08-03 11:29:00 | n |
| 184686 | IIEES SC | TAFT | Z | 0.04 | 1 | 2023-08-02 17:24:10 | 2023-08-03 11:29:00 | n |
| 184687 | IIEES SC | SHRO | Z | 0.02 | 1 | 2023-08-02 17:24:10 | 2023-08-03 11:29:00 | n |
| 184688 | IIEES SC | TBJM | Z | 0.08 | 1 | 2023-08-02 17:24:12 | 2023-08-03 11:29:00 | n |
| 184689 | IIEES SC | JRKH | Z | 0.03 | 1 | 2023-08-02 17:24:18 | 2023-08-03 11:29:00 | n |
| 184690 | IIEES SC | NASN | Z | 0.02 | 1 | 2023-08-02 17:24:21 | 2023-08-03 11:29:00 | n |
| 184691 | IIEES SC | KBAM | Z | 0.08 | 1 | 2023-08-02 17:24:22 | 2023-08-03 11:29:00 | n |
| 184692 | IIEES SC | MRVT | Z | 0.008 | 1 | 2023-08-02 17:24:31 | 2023-08-03 11:29:00 | n |
Phase | ||||||||||||
| Agency | Station | Component | Phase Type | Phase Quality | First Motion | Observed Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth | |
| IIEES SC | TABS | Z | EPg | E | 2023-08-02 17:23:32 | 0.3 | y | 0 | 75 | 334 | ||
| IIEES SC | TABS | Z | ESg | E | 2023-08-02 17:23:42 | 1 | y | 0 | 75 | 334 | ||
| IIEES SC | KKHK | Z | EPg | E | 2023-08-02 17:23:45 | -0.7 | y | 0 | 162 | 42 | ||
| IIEES SC | KKHK | Z | ESg | E | 2023-08-02 17:24:05 | 0.1 | y | 0 | 162 | 42 | ||
| IIEES SC | SHRT | Z | EPn | E | 2023-08-02 17:24:00 | -0.3 | y | 0 | 271 | 76 | ||
| IIEES SC | SHRT | Z | ES | E | 2023-08-02 17:24:30 | -0.3 | y | 0 | 271 | 76 | ||
| IIEES SC | YZKH | Z | EPn | E | 2023-08-02 17:24:01 | -0.6 | y | 0 | 280 | 255 | ||
| IIEES SC | MEH | Z | EPn | E | 2023-08-02 17:24:07 | 0.2 | y | 0 | 326 | 236 | ||
| IIEES SC | TAFT | Z | EPn | E | 2023-08-02 17:24:10 | 0.1 | y | 0 | 344 | 245 | ||
| IIEES SC | KRBR | Z | EPn | E | 2023-08-02 17:24:04 | -5.7 | n | 4 | 346 | 191 | ||
| IIEES SC | SHRO | Z | EPn | E | 2023-08-02 17:24:10 | -0.9 | y | 0 | 355 | 338 | ||
| IIEES SC | TBJM | Z | EPn | E | 2023-08-02 17:24:12 | 0.2 | y | 0 | 361 | 47 | ||
| IIEES SC | SBZV | Z | EPn | E | 2023-08-02 17:24:13 | 0.5 | y | 0 | 371 | 2 | ||
| IIEES SC | JRKH | Z | EPn | E | 2023-08-02 17:24:18 | 0 | y | 0 | 413 | 40 | ||
| IIEES SC | NASN | Z | EPn | E | 2023-08-02 17:24:21 | -0.2 | y | 0 | 437 | 266 | ||
| IIEES SC | KBAM | Z | EPn | E | 2023-08-02 17:24:22 | 0.2 | y | 0 | 443 | 168 | ||
| IIEES SC | MRVT | Z | EPn | E | 2023-08-02 17:24:31 | -0.8 | y | 0 | 527 | 346 | ||
