Magnitude |
:2.8 |
| Date & Time (UTC) | 2018-11-01 03:04:16.1 |
| Date & Time (Local) | 1397/8/10 06:34:16.1 |
| Location | Lat:34.653 Lon: 46.269 |
| Region | Kermanshah Province, 26 km South-West of Javanrud |
Nearest Cities |
|
| 5 km of Mirabad, Kermanshah Province | |
| 13 km East of Qolqoleh, Kermanshah Province | |
| 18 km North of Zavleh olia, Kermanshah Province | |
| 19 km West of Dolatabad, Kermanshah Province | |
| 20 km South West of Sarukhan, Kermanshah Province | |
| Depth | 15 km |
| Agency | |
Faults within 150 km: |
|
| HZF4 (Length: 492 km) , Distance to epicenter: 12 km | |
| MFF8 (Length: 48 km) , Distance to epicenter: 36 km | |
| SARTAKHT_F (Length: 78 km) , Distance to epicenter: 57 km | |
| Number of Phases | 7 |
| RMS | 0.4 |
| Number of Stations | 5 |
| Error in Latitude | >2.9 km |
| Error in Longitude | 5.1 km |
| Error in Depth | 7.3 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude | ||||||||
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
| 138179 | IIEES | SNGE | E | 203.3 | 0.3 | 2018-11-01 03:04:51 | 2018-11-03 10:30:00 | n |
| 138180 | IIEES | SNGE | N | 218.1 | 0.35 | 2018-11-01 03:04:52 | 2018-11-03 10:30:00 | n |
| 138181 | IIEES | ILBA | N | 291 | 0.31 | 2018-11-01 03:04:57 | 2018-11-03 10:30:00 | n |
| 138182 | IIEES | ILBA | E | 267.2 | 0.35 | 2018-11-01 03:04:57 | 2018-11-03 10:30:00 | n |
| 138183 | IIEES | SRSL | E | 100.1 | 0.46 | 2018-11-01 03:05:15 | 2018-11-03 10:30:00 | n |
| 138184 | IIEES | SRSL | N | 110.3 | 0.37 | 2018-11-01 03:05:16 | 2018-11-03 10:30:00 | n |
| 138185 | IIEES | KHMZ | E | 11.8 | 0.5 | 2018-11-01 03:06:10 | 2018-11-03 10:30:00 | n |
Phase | ||||||||||||
| Agency | Station | Component | Phase Type | Phase Quality | First Motion | Observed Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth | |
| IIEES | SNGE | Z | Pg | E | 2018-11-01 03:04:33 | -0.91 | y | 110 | 63 | |||
| IIEES | SNGE | N | Sg | E | 2018-11-01 03:04:48 | 0.18 | y | 110 | 63 | |||
| IIEES | ILBA | Z | Pg | E | 2018-11-01 03:04:35 | -0.13 | y | 114 | 183 | |||
| IIEES | ILBA | E | Sg | E | 2018-11-01 03:04:49 | -0.07 | y | 114 | 183 | |||
| IIEES | SRSL | Z | Pg | E | 2018-11-01 03:04:47 | 0.16 | y | 189 | 337 | |||
| IIEES | ASAO | Z | Pn | E | 2018-11-01 03:05:06 | 0.23 | y | 345 | 91 | |||
| IIEES | KHMZ | Z | Pn | E | 2018-11-01 03:05:08 | 0.67 | y | 355 | 106 | |||
